Powerful and quick. Clean and efficient. A 4-stroke for all purposes.
SPECIFICATIONS
| MODEL |
DF175A |
|---|
| RECOMMENDED TRANSOM HEIGHT mm (in.) |
L:508 (20), X:635 (25) |
|---|
| STARTING SYSTEM |
Electric |
|---|
| WEIGHT kg *1 |
L:235, X:240 |
|---|
| ENGINE TYPE |
DOHC 16-Valve |
|---|
| FUEL DELIVERY SYSTEM |
Multi-Point Sequential Electronic Fuel Injection |
|---|
| NO. OF CYLINDERS |
In-Line 4 |
|---|
| PISTON DISPLACEMENT cm3 (cu.in.) |
2,867 (174.9) |
|---|
| BORE × STROKE mm (in.) |
97 × 97 (3.81× 3 .81) |
|---|
| MAXIMUM OUTPUT kW (PS) |
129.0 (175) |
|---|
| FULL THROTTLE OPERATING RANGE rpm |
5,500-6,100 |
|---|
| STEERING |
Remote |
|---|
| OIL PAN CAPACITY Lit. (U.S. qt) |
8.0 (8.5) |
|---|
| IGNITION SYSTEM |
Fully-transistorized |
|---|
| ALTERNATOR |
12V 44A |
|---|
| ENGINE MOUNTING |
Shear Mount |
|---|
| TRIM METHOD |
Power Trim and Tilt |
|---|
| GEAR RATIO |
2.50:1 |
|---|
| GEAR SHIFT |
F-N-R |
|---|
| EXHAUST |
Through Prop Hub Exhaust |
|---|
PROPELLER SELECTION (Pitch) *2
3 blades and 4 blades propeller are available. |
15"-27.5"(R/R), 17"-26(C/R) |
|---|
