If an engine with performance is an essential part of your boating life, then you need our combination of quality, reliability and choice.
| MODEL |
DF140A *3 |
|---|
| RECOMMENDED TRANSOM HEIGHT mm |
L: 508, X: 635 |
|---|
| STARTING SYSTEM |
Electric |
|---|
| WEIGHT kg *1 |
L: 179, X: 184 |
|---|
| ENGINE TYPE |
DOHC 16-Valve |
|---|
| FUEL DELIVERY SYSTEM |
Multi-Point Sequential Electronic Fuel Injection |
|---|
| NO. OF CYLINDERS |
4 |
|---|
| PISTON DISPLACEMENT cm3 |
2,044 |
|---|
| BORE ×STROKE mm |
86 x 88 |
|---|
| MAXIMUM OUTPUT kW |
103.0 |
|---|
| FULL THROTTLE OPERATING RANGE rpm |
5,600-6,200 |
|---|
| STEERING |
Remote |
|---|
| OIL PAN CAPACITY Lit. |
5.5 |
|---|
| IGNITION SYSTEM |
Fully-transistorized |
|---|
| ALTERNATOR |
12V 40A |
|---|
| ENGINE MOUNTING |
Shear Mount |
|---|
| TRIM METHOD |
Power Trim and Tilt |
|---|
| GEAR RATIO |
2.59:1 |
|---|
| GEAR SHIFT |
F-N-R |
|---|
| EXHAUST |
Through Prop Hub Exhaust |
|---|
PROPELLER SELECTION (Pitch)*2
All propellers are the 3-blade type |
15"-25" |
|---|
